Tomson Leak Protection Valve
Regular price
$205.00
Regular price
$0.00
Sale price
$205.00
Unit price
per
Shipping calculated at checkout.
Couldn't load pickup availability
Leak protection valves are certified to Standard WMTS-476:2016 as a device providing protection against damage from leaking water under AS/NZS 3500.4:2018
Product Specifications
Size and Dimensions
| Size | 15mm |
|---|---|
| Cable Length | 1 mtr |
Inclusions and Exclusions
| Items Sold Separately | 2571001 - Universal 240V Power-Pack Lpv. Required for 240V mains connection. |
|---|
Features
| Designed to work with all Hot Water Safe Trays, but works best with Tomson Safe Trays. | |
| The Red TRIP LED will flash and alarm will sound when the sensor has been triggered. The valve will then close, shutting off supply to the hot water unit. | |
| Flexible installation, can be installed up to 1m above Safe Tray | |
| Battery operated | |
| Universal power-pack available for constant 240V power supply |
General Information
| Installation | Internal |
|---|---|
| Manufacturing Information | Australian Made |
| Product Type | Leak Protection Valve |
| Watermark Certified | Yes |
Material
| Body Material | Plastic & Brass, compression nut & olive connections |
|---|
Technical Information
| Connection Type | Compression x Compression |
|---|---|
| Standards | AS/NZS 3500.4:2018 |
Pressure Information
| Maximum Inlet Pressure | 2500 kPa |
|---|
Temperature Information
| Maximum Inlet Temperature | 90 deg C |
|---|
Power Information
| Battery Type | 4 x AA |
|---|
Warranty Information
Warranty
| Product Warranty | 2 Years |
|---|
